| -n |
Runs without changing the kernel forwarding table. This is useful for
testing, and when operating as a route server which does no
forwarding. |
| -q |
Runs quietly. With this flag informational messages which are
normally printed to the standard output are suppressed and error
messages are logged with syslogd instead of being
printed to the standard error output. This is convenient
when running gdc from a shell script. |
| -t seconds |
Specifies the time in seconds that gdc
waits for gated to complete certain operations,
in particular at termination and startup. By default this value
is set to 10 seconds. |
| -c coresize |
Sets the maximum size of a core dump a gated started
with gdc produces. This is useful on systems where
the default maximum core dump size is too small for
gated to produce a full core dump on errors. |
| -f filesize |
Sets the maximum file size a gated started with
gdc will produce. Useful on systems where the
default maximum file dump size is too small for gated to
produce a full state dump when requested. |
| -m datasize |
Sets the maximum size of the data segment of a gated
started with gdc. Useful on systems where the
default data segment size is too small for gated to run. |
| -s stacksize |
Sets the maximum size of stack of a gated started with
gdc. Useful on systems where the default maximum
stack size is too small for gated to run. |
| COREDUMP |
Sends an abort signal to gated, causing it to terminate
with a core dump. |
| dump |
Signals gated to dump its current state into the file
/var/tmp/gated_dump. |
| interface |
Signals gated to recheck the interface configuration.
gated normally does this periodically in any event, but
the facility can be used to force the daemon to check interface
status immediately when changes are known to have occured. |
| KILL |
Causes gated to terminate ungracefully. |
| reconfig |
Signals gated to reread its configuration file,
reconfiguring its current state as appropriate. |
| term |
Signals gated to terminate after shutting down all
operating routing protocols gracefully. Executing this command a
second time causes gated to terminate even if some
protocols have not yet fully shut down. |
| toggletrace |
Causes tracing to be suspended, and if gated is currently tracing
to a file, closes the trace file. If
gated tracing is current suspended, this subcommand causes the trace
file
to be reopened and tracing initiated. This is useful for moving
trace files. |
The following subcommands perform operations related to configuration files:
| checkconf |
Check /etc/gated.conf for syntax errors. This is
usefully done after changes to the configuration file but before
sending a reconfig signal to the currently
running gated, to ensure that there are no errors in the
configuration which would cause the running gated to
terminate on reconfiguration. When this command is used,
gdc issues an informational message indicating
whether there were parse errors or not, and if so saves the error
output in a file for inspection. |
| checknew |
Like checkconf except that the new
configuration file, /etc/gated.conf+, is checked
instead. |
| newconf |
Move the /etc/gated.conf+ file into place as
/etc/gated.conf, retaining the older versions of the
file as described above. gdc will decline to do
anything when given this command if the new
configuration file doesn't exist or otherwise looks suspect. |
| backout |
Rotate the configuration files in the newer direction,
in effect moving the old configuration file to
/etc/gated.conf. The command will decline to perform the
operation if /etc/gated.conf- doesn't exist or is zero
length, or if the operation would delete an existing, non-zero
length /etc/gated.conf+ file. |
| BACKOUT |
Perform a backout operation even if
/etc/gated.conf+ exists and is of non-zero length. |
| modeconf |
Set all configuration files to mode 664, owner root, group
system. |
| createconf |
If /etc/gated.conf+ does not exist, create a zero length
file with the file mode set to 664, owner root, group system. |
The following subcommands provide support for starting and stopping
| running |
Determine if gated is currently running. This is done
by checking to see if gated has a lock on the file
containing its pid, if the pid in the file is sensible and if
there is a running process with that pid. Exits with zero status
if gated is running, non-zero otherwise. |
| start |
Start gated. The command returns an error if
gated is already running. Otherwise it executes the
gated binary and waits for up to the delay interval (10
seconds by default, as set with the -t option
otherwise) until the newly started process obtains a lock on the
pid file. A non-zero exit status is returned if an error is
detected while executing the binary, or if a lock is not obtained
on the pid file within the specified wait time. |
| stop |
Stop gated, gracefully if possible, ungracefully if not.
The command returns an error (with non-zero exit status) if
gated is not currently running. Otherwise it sends a
terminate signal to gated and waits for up to the delay
interval (10 seconds by default, as specified with the
-t option otherwise) for the process to exit.
Should gated fail to exit within the delay interval it
is then signaled again with a second terminate signal. Should it
fail to exit by the end of the second delay interval it is
signalled for a third time with a kill signal. This should force
immediate termination unless something is very broken. The
command terminates with zero exit status when it detects that
gated has terminated, non-zero otherwise. |
| restart |
If gated is running it is terminated via the same
procedure as is used for the stop command above.
When the previous gated terminates, or if it was not
running prior to command execution, a new gated process is
executed using the procedures described for the
start command above. A non-zero exit status is
returned if any step in this procedure appears to have failed. |
The following subcommands allow the removal of files created by the
execution of some of the commands above:
